4509 13V 100W PAR36 Sealed Beam Lamp
4509 GE 13V 100W Aircraft

GE $8.18 each

Lamps ordered will be shipped the next day by USPS Priority Mail or UPS. Large orders may qualify for a discount and may not qualify for next day shipment. If you do not know what lamp you require or for lamps not listed, email your request or call 336-882-2854. To order, please use our secure shopping cart below or call 800-692-3051. Click to go to our Home Page, View Cart and to find Shipping Information.



Click below to order using our secure shopping cart.

Wattage: 100W, 100 Watt Watts
Voltage: 13V, 13 Volt Volts
Glass: PAR36, PAR 36, 4.5" Diameter
Base: Screw Terminals
Filament: C-6, C6
Average Rated Life: 25 hours
Technology: Incandescent
Beam Spread: Horizontal 12° - 10 %
Beam Spread: Vertical 6° - 10 %
Max. Beam Candlepower (MBCP) (MAX) 110,000
Maximum Overall Length (MOL) 2.75"/69.8mm
Bulb Diameter (DIA) 4.5"/114.3mm

Alternate Part Numbers: 24649 24650

Aircraft Landing Spotlamp

graphicpar36-1.gif     graphic2screw-1.gif


Beech
36 t
77
A36
B19
C23
C24R
E33A
E33
N35
P35
S35
V35

Cessna
150K-M
152
172M
172N-28V
172
180
185
205
206
207
A188B
T207

Piper
PA28-151
PA34-200T
PA34-220T
Tomahawk PA-37-112


Programmi and Sistemmi
SUPER-CAROUSEL
VECTOR



Cross reference information is designed to help you find the correct lamp for your application. We do not verify the accuracy of this information. You are responsible for ordering the correct lamp and we make every attempt to help you in that process. We recommend that you confirm the information with the equipment manufacturer before ordering.
