GE 261 2.5V .35A Midget Groove Lens End Light Bulb Replacement Lamp
31 Remaining In Stock
GE $5.00 Each
Recommended Replacements: 253, 253X
Lamps ordered will generally be shipped the next business day by USPS Priority Mail or UPS, check here for Shipping Information. Large orders may qualify for a discount and may not qualify for next day shipment. If you do not know what lamp you require or for lamps not listed, email your request or call 336-882-2854. To order, please use our secure shopping cart or call 336-882-2852 or 800-692-3051. Click to go to our Home Page and View Cart.
Voltage: 2.5V
Wattage: 1W, .88W, .875W
Amperage: .35A, 350mA
Filament: C-2R
Maximum Overall Length: .69" or 17.5mm
Maximum Overall Diameter: .23" or 5.9mm
Light Center Length: .38"/9.6mm
Average Rated Life: 10,000 Hours
MSCP: .34CP
Lumens: 4.27
Bulb: TL-1 3/4, TL1.75, Lens End
Base: Midget Groove, Grooved, S5.7s, MID GRV
Typical Use: Aircraft, Airplane, Indicator, Elevator, Instrument
Side solder within 25° of plane of filament. With lamp horizontal and side solder in uppermost position, the following beam pattern limits are provided on the surface perpendicular to the base axis and located 3/8" from end of bulb. 750 footcandles minimum over a 1/16" diameter circle centered on base axis. While the entire beam may not be centered on base axis, it will cover at least a 1/8" circle centered on the base axis. EFC values will vary depending on the type of equipment used for measurement.
Alternate Part Numbers: GE261, GE 28475, NSN 6240-00-916-1638
Cross reference information is designed to help you find the correct lamp for your application. We do not verify the accuracy of this information. You are responsible for ordering the correct lamp and we make every attempt to help you in that process. We recommend that you confirm the information with the equipment manufacturer before ordering.
